Looking for a spring tine cultivator that keeps working when it hits stones, roots or hardpan? The Raydafon 3ZT series is a tractor-mounted secondary tillage implement built for row-crop intertillage and deep loosening. Its dual-spring tensioning device lets every tine kick up over an obstruction and snap straight back to working depth — protecting the tine and keeping your pass uninterrupted, pass after pass.
Developed by Raydafon Power specifically against the demands of the international farm equipment market, the 3ZT spring tine cultivator uses a dual-spring straining device on each tine assembly. When a tine meets an obstruction, the shank lifts automatically and returns to its original working position once the obstacle is cleared — the shank is protected, and the operator never has to stop, reverse or dismount.
Row pitch adjustment is quick and tool-light, and working depth is equally easy to set, so one machine can be re-configured between corn, cotton, beans and peas without a workshop visit.
The dual-spring straining device lifts the shank over stones and roots, then restores working depth automatically. Fewer broken tines, fewer unplanned stops, longer service life in stony ground.
Both row spacing and working depth are adjusted with simple mechanical settings, so one cultivator covers multiple crops and growth stages across your season.
Four frame sizes from 1.0 m to 2.2 m working width fit the compact and mid-range tractors most commonly used for row-crop intertillage worldwide.
Consistent depth across all four models delivers even weed control and soil loosening without burying the crop row or cutting too shallow.
Custom colour, decals, packaging and dimensional adaptation are available for distributors, importers and private-label brands.
Heavy-gauge welded frame and hardened spring steel tines, produced in an ISO 9001 certified facility with full inspection records.
| Model | Unit | 3ZT-1.0 | 3ZT-1.4 | 3ZT-1.8 | 3ZT-2.2 |
|---|---|---|---|---|---|
| Working width | m | 1.0 | 1.4 | 1.8 | 2.2 |
| No. of tines | pc | 5 | 7 | 9 | 11 |
| Working depth | mm | 100 – 200 | |||
| Total weight | kg | 260 | 300 | 350 | 420 |
| Matched power | HP | 25 | 30 – 40 | 40 – 50 | 50 – 70 |
All models are three-point mounted and suit standard Category I / II tractor linkages. If your tractor horsepower or row spacing falls outside the table above, tell us your requirement and we will recommend the closest standard frame or quote a customized build.
Most importers buy the cultivator together with its driveline and matching soil-engaging components to reduce freight cost per unit. Raydafon manufactures the full set in-house:
Raydafon Power is a China-based cultivator manufacturer and supplier serving global OEM markets. We are not a trading desk — the cultivator, its driveline and the transmission parts behind it are produced under one roof, which is why lead times and tolerances stay predictable order after order.
You can review our factory, inspection equipment and why customers choose us before you place an order.
Frames are loaded onto pallets and secured for container shipment, while all loose parts — tines, clamps, bolts and fittings — are packed into an iron case so nothing goes missing in transit. Standard export packing is designed for stacking and for the handling conditions of long-sea freight.
Full details are available on our packing and shipping page.
Send us your model, quantity and destination port — we will reply with price, lead time and packing details.
