Product Performance | ||||
Max Input Torque | T max | 22N.m | ||
Max Input Rotation Rate | n max | 4500r/min | ||
Centre.to-centre Spacing | A | 136mm | ||
Gear Ratio | U | 10.088 | ||
Input & Output Spline Parameters | ||||||
Tooth system | Input internal spline | Output end internal spline | ||||
modulus | m | 1 | 1 | |||
number of teeth | z | 18 | 25 | |||
Pressure angle | a | 20° | 45° | |||
the modification coefficient | x | 0.8 | 0.1 | |||
Over Dimension & Weight | ||
Weight(kg) | 38.5 | |
Length | 1302 | |
AxleTrack | 352 | |
Height | 251 | |
For more details, please click here to contact us！ | ||||||||
