High Precision Angular Contact Ball Bearing for Engine Gear Bearing Machine Spindle

High Precision Angular Contact Ball Bearing for Engine Gear Bearing Machine SpindleProducts DescriptionHigh Quality Angular Contact Ball BearingIn angular bearings the line of action of the load, at the contacts between balls and raceways, forms an angle with the bearings axis. The inner and outer r......
Send Inquiry
Product Description

High Precision Angular Contact Ball Bearing for Engine Gear Bearing Machine Spindle

High Precision Angular Contact Ball Bearing for Engine Gear Bearing Machine Spindle
Products Description

High Quality Angular Contact Ball Bearing

In angular bearings the line of action of the load, at the contacts between balls and raceways, forms an angle with the bearings axis. The inner and outer rings are offset to each other and the bearings are particularly suitable for carrying combined radial and axial loads. The single row bearing is of non-separable design, suitable for high speeds and carries an axial load in one direction only. A bearing is usually arranged so that it can be adjusted against a second bearing.

Angular bearings can carry both radial and axial loads. The weight of the load is transferred from one ring to the other, through the balls, along a specific contact angle.

Contact angles of 15°, 25° and 40° are common. The larger the contact angle, the higher the axial load capacity. At the same time, the maximum speed limit is reduced as the contact angle increases.
High Precision Angular Contact Ball Bearing for Engine Gear Bearing Machine Spindle
For more details, please click here to contact us！
Number of row
Double Row
Size
20*52*28mm
Seal
2RS,ZZ
Operating temperature range:
-30 to +120 °C
Maximum rpm:
300RPM
Ceetificate
ISO9001:2008
