High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer

High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear ReducerProduct DescriptionProduct Characteristics1. Drive by hypoid gear, has big ratios.2. Large in output torque, high efficiency, energy saving and environmental protection.3. Made of high quality aluminum alloy, light in weigh......
Send Inquiry
Product Description

High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer

Product Description
Product Characteristics

1. Drive by hypoid gear, has big ratios.

2. Large in output torque, high efficiency, energy saving and environmental protection.

3. Made of high quality aluminum alloy, light in weight and non-rusting

4. Smooth in running and low in noise, can work long in dreadful conditions.

5. Good-looking in appearance, durable in service life and small in volume.

6. Suitable for all round installation, wide application and easy of use.

7. The Mounting Dimension of BKM series are compatible with NMRV series worm gear unit (A part of NMRV050 dimensions are different
from BKM050)

8. Modular and multi-structure can meet the demands of various conditions.


TYPE
BKM50,BKM63,BKM75,BKM90,BKM110
Transmission Stage
B: 2 stages C: 3 stages
Ratio
B: 7.5,10,12.5,15,20,25,30,40,50,60 C: 50,60,75,100,125,150,200,250,300
Output torque
Up to 500N.m
Motor power
0.12~5.5KW
Housing material
Aluminum alloy
Output shaft material
 40Cr
Hardness level
242-286HB
Helical gear Material
20CrMnTi
Hardness level
58-62HRC
Precision level
6 grade
Transmission efficiency
B:92%-94% C:90%-92%
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
Click Here for more types！
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
Click the picture below to view more raleted products！
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
High Precision BKM Series Double Hypoid Helical Gear Reducer BKM Gear Reducer
