Model | HC550A-1 |
Nominal voltage input | 220V 50Hz |
Power at rated pressure | ≦550W @200Kpa |
Current at rated pressure | 2.5A @ 200Kpa |
Air flow rate at rated pressure | ≥130L/min @ 200Kpa |
Noise | ≤61dB(A) |
Configure capacitor | 18μF |
Safe valve set pressure | 280Kpa |
Dimension | 240*113*200 mm |
Installation size | 89*203 mm (4*M6) |
Net Weight | 10.4 KG |
Use environment | -5~40℃ |
Lead wire length (mm) | 650±20 mm |
Temperature rise | ≤60K |
