The 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain is a flat top chain with a rubberised top surface that increases grip between the chain and the product being conveyed. The chain is built on the standard 1005 1-inch pitch geometry, so it runs on any 1005 series sprocket without modification, but the top surface is over-moulded with a high-friction rubber layer that stops glass bottles, PET bottles, cans and cartons from sliding on inclines, in accumulation zones and through transfer points. The chain is moulded from POM (acetal) for the base and food-grade rubber for the top surface, making it suitable for direct food contact lines.
Raydafon manufactures the 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain at the Hangzhou factory as an ISO 9001 certified manufacturer. Standard width is 82.6 mm; other widths can be produced to order. The chain is supplied in standard length runs and cut-to-length on request. Matching sprockets in the 1005 series with 19, 21 or 23 teeth are supplied from the same factory so the chain and sprocket interface is confirmed as a matched set.
A 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain is a flat top conveyor chain that uses the standard 1005 series 1-inch pitch geometry with a rubberised top surface. The base chain is moulded from POM (acetal), which gives the chain its dimensional stability and low friction against the wear strip. The top surface is over-moulded with a food-grade rubber layer that sits above the plastic links and increases grip against the product being carried. This combination is used where the conveyor runs on an incline, where products accumulate under pressure, or where the product is slippery (glass bottles, PET bottles, aluminium cans) and a plain flat top chain would allow the product to slide or tip.
The 1005 series 25.4 mm pitch is the standard 1-inch pitch used across the plastic chain range. Because the pitch and link width are standard, the rubber surface 1005 chain runs on any 1005 series sprocket without modification. The rubber top layer does not affect the pin and link geometry, so chain length is calculated the same way as for a plain 1005 chain.
The table below lists the full dimensional and material specification of the 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain. Custom widths and pitch options are available when the standard width does not match the conveyor layout.
| Chain Series | 1005 series flat top chain |
| Chain Pitch | 25.4 mm (1 inch) |
| Standard Chain Width | 82.6 mm |
| Base Material | POM (acetal) |
| Top Surface Material | Food-grade rubber |
| Top Surface Function | Non-slip grip between chain and product |
| Chain Type | Flat top, straight running |
| Matched Sprocket | 1005 series, 19T / 21T / 23T |
| Operating Temperature | -40 °C to +90 °C (POM base); rubber top limited to +80 °C continuous |
| Working Load | Confirmed against conveyor layout and product weight |
| Colour | White base with black or white rubber top |
| Certification | ISO 9001 |
| Applications | Beverage, food filling, pharmaceutical, consumer goods, paper and carton |
The 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain is specified on six main conveyor functions inside the food, beverage, pharmaceutical and packaging industries. The functional roles below are the ones most often quoted on a Raydafon enquiry.
Straight-run conveyor sections where one or more product lanes feed a filler, capper or labeller. The rubber surface keeps bottles and cans from drifting between guide rails.
Accumulation zones where the product backs up against a stop. The rubber surface lets the chain continue to run underneath the stationary product without scratching the base of the bottle or can.
Sloped conveyor sections where a plain flat top chain would allow the product to slide. The rubber surface increases the friction coefficient enough to carry the product up or down a slope.
Feed and discharge sections on palletisers and stacking platforms where the case has to be positioned without slipping before it is picked up.
Transfer sections at the inlet or outlet of a packaging machine where the carton or bottle has to be handed off cleanly from one conveyor to the next.
Heavily loaded packages that need to speed up, slow down or turn on a slope where a non-slip surface is required to keep the package under control.
A plain flat top chain is cheaper, so the choice of a rubber surface 1005 chain is always driven by the conveyor layout. The five reasons below are the ones that most often justify the upgrade.
The rubber surface increases the friction between chain and product, so bottles, cans and cartons stay in position on an incline where a plain chain would allow them to slide back down.
In an accumulation zone, the chain keeps running while the product is held stationary. The rubber surface is softer than a bare POM surface, so it does not scratch the base of the bottle or leave marks on the can.
On multi-lane conveyors the rubber surface keeps the product in the same lane position from the infeed to the discharge, which reduces jams and stabilises the infeed to downstream equipment.
The rubber layer absorbs part of the impact when the product drops onto the chain at a transfer point, so the conveyor runs quieter than a bare flat top chain.
The base is POM (acetal) and the top surface is a food-grade rubber compound. Both materials are suitable for direct food contact lines and can be cleaned with standard CIP chemicals.
The chain runs on the standard 1005 series sprocket with the standard 25.4 mm pitch. Where a line already uses 1005 series chain, upgrading to the rubber surface version does not require changing the sprocket or the conveyor frame.
The 1005 series covers a wide range of flat top chain variants at the same 25.4 mm pitch, so the correct chain for a given line is defined by the top surface and the opening pattern, not the pitch. The table below lists the standard 1005 series options that Raydafon produces. Custom variants can be produced to a drawing or sample.
| 1005 Series Variant | Pitch | Top Surface | Typical Use |
|---|---|---|---|
| 1005 Standard Flat Top | 25.4 mm | Plain POM | Straight-run conveying of stable products |
| 1005 Rubber Surface | 25.4 mm | Food-grade rubber | Incline, decline and non-slip conveying |
| 1005 Dynamic Transition | 25.4 mm | Plain POM with transition edge | Small-pitch transfer points and dynamic transfers |
| 1005 Hollow Flat Top | 25.4 mm | Plain POM with hollow openings | Drainage, airflow and light-weight conveying |
| 1005 Straight Running | 25.4 mm | Plain or rubber | Standard straight conveyor sections |
| 1005 Side Flexing | 25.4 mm | Plain or rubber | Curved conveyor sections and carousel lines |
The rubber surface variant is supplied as a complete chain with the rubber top over-moulded. Replacement rubber inserts are available separately for maintenance. Raydafon also supplies matching 1005 series sprockets in 19T, 21T and 23T to complete the drive interface.
To confirm the correct 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain and issue a quotation, Raydafon needs the five items below. For a straight replacement of an existing 1005 rubber surface chain, the original chain code alone is usually enough.
Send the five items below and Raydafon will confirm the specification, chain length, sprocket match and lead time within one working day.
The 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain is used on conveyor lines where a plain flat top chain would allow the product to slide. Typical uses are incline and decline conveying, pressure-free accumulation, multi-lane bottle and can lines, palletiser feed sections and packaging machine infeed and outfeed.
The 1005 series chain pitch is 25.4 mm (1 inch). The standard chain width is 82.6 mm. Other widths can be produced to order when the conveyor layout requires a wider or narrower chain.
The base chain is moulded from POM (acetal), which provides dimensional stability and low friction against the wear strip. The top surface is a food-grade rubber layer that is over-moulded onto the plastic links. Both materials are suitable for food contact lines.
Yes. The rubber surface does not change the pitch or link geometry, so the chain runs on any 1005 series sprocket. Raydafon supplies matching 1005 sprockets in 19T, 21T and 23T as a matched set with the chain.
The POM base is rated for -40 °C to +90 °C. The rubber top surface is limited to +80 °C continuous because the rubber compound will start to harden above that temperature. For higher temperature applications Raydafon can supply alternative top surface materials.
Yes. The chain is supplied in standard length runs, or cut to length on request. For a cut-to-length order, send the required total chain length in metres or the number of links and Raydafon will confirm the correct chain length and the number of pins required.
Common applications are glass bottle and can conveying, food filling lines, pharmaceutical packing, consumer goods handling, papermaking and carton making. The chain is designed for beverage, food, pharmaceutical and packaging industries.
Standard configurations ship in 15 to 30 days. Custom widths and cut-to-length orders are confirmed with the quotation. MOQ depends on the specific configuration and is confirmed when the specification is fixed. Raydafon supplies OEM, project and factory-direct quantities from the Hangzhou factory.
Whether you are replacing a worn rubber surface chain on an existing beverage line, upgrading a plain flat top conveyor to non-slip transport, or sourcing 1005 series chain and sprockets in volume for a food or pharmaceutical line, Raydafon can quote the 1005 Series 25.4mm Pitch Rubber Surface Plastic Chain to your width, length and sprocket requirements. OEM and project quantities supplied directly from the Hangzhou factory.
