Wholesale Quality 2000lbs TR1819 Side Wind Trailer Jack

Wholesale Quality 2000lbs TR1819 Side Wind Trailer JackProducts Description2000 pound trailer jackThe function of the semi-trailer legs is to support the ground when the tractor and trailer are uncoupled, bear the load of the front half of the semi-trailer, and rotate the crank to raise the support ......

Send Inquiry

Product Description

Wholesale Quality 2000lbs TR1819 Side Wind Trailer Jack

Products Description

2000 pound trailer jack The function of the semi-trailer legs is to support the ground when the tractor and trailer are uncoupled, bear the load of the front half of the semi-trailer, and rotate the crank to raise the support device in two gears: fast gear and slow gear. When unloaded, it is in high gear, and when overloaded, it is in low gear.

Load capacity	2000lbs
Travel	15"
Pipe Size	57mm/51mm
Surface	Black powder coated outer tube,Galvanized inner tube

Maintenance of Trailers 1. Daily maintenance (1) After each operation, the trailer body and chassis should be cleaned in a timely manner. (2) Check if all safety devices and light pens are reliable. (3) Check whether the steel plate springs and U-bolts on the front and rear axles of the trailer are loose, displaced, cracked, or broken. (4) Check the inflation condition of the tires and inflate them according to regulations, with an error not exceeding ± 0.5kg/cm ². In addition, check the tightness of the nuts on each wheel.

2. Trailers should undergo the following maintenance every 600 to 800 kilometers traveled: (1) Check the steel plate springs, bushings, and pins. If the wear of the steel plate spring pin exceeds 1.5mm, the gap between the pin and the bushing is too large and should be replaced. (2) According to regulations, lubricate each part, check the clearance of each hub bearing, adjust if necessary, and add calcium based grease. (3) Check if there are cracks in the welding points of the frame, if the connecting bolts are loose, and check the sealing of the braking system and the vehicle's main brake control mechanism. 3. When driving a trailer for 3000-4000 kilometers, in addition to the above maintenance, the following maintenance should also be carried out: (1) Clean and adjust the hub bearings, and add lubricating grease; Clean and inspect the wear of the spring steel plate, and make necessary repairs or replacements; To adjust the bearing clearance, first tighten the adjusting nut to the end, then retract it by 1/6 turn, and then tighten it. (2) Check and adjust the brake, and repair or replace it based on the wear of the brake drum. The brake cannot be adjusted too tightly. When the unit is driving at a speed of 18km/h, the wheel brake mark should be 4-5m. (3) Check the traction frame, main frame, wheel axles, and other components for bending, deformation, and cracks, and repair them if necessary.
