Product Model | WT-125 | Segmentation accuracy | 20 ″ |
Disk Diameter | Φ125mm | Repeat positioning | 4 ″ |
Center Diameter | Φ40mm | Locking Mode | 13kg.m |
Spindle Hole | Φ22mm | Servo Motor | β4is;HF-105 |
Center Height | 110mm | Speed Reduction Ratio | 1:60 |
T-Slot Width | 12H7mm | Maximun Speed | 66r.p.m |
Positioning Button | 14H7mm | Allowable Work Inertia | 2kg.cm.sec2 |
Min lncrement | 0.001° | Allowable Cutting Torque | 9Kg.m |
Weight（Without Motor） | 40Kg | Vertical | 50KG |
Horizontal | 80KG | Tailstock applied | 80KG |
