WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC Machinery

WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC MachineryProducts DescriptionLarge aperture design High segmentation accuracy high rigidity and high performanceHigh efficiency and strong braking structure systemProduct ModelWT-320-2PSegmentation accuracy15 ″Disk Diame......
Send Inquiry
Product Description

WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC Machinery

WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC Machinery
Products Description
Large aperture design High segmentation accuracy high rigidity and high performance
High efficiency and strong braking structure system
Product Model
WT-320-2P
Segmentation accuracy
15 ″
Disk Diameter
Φ320mm
Repeat positioning
4 ″
Center Diameter
Φ110H7mm
Locking Mode
115kg.m
Spindle Hole
Φ110mm
Servo Motor
β22is;HF-204
Center Height
210mm
Speed Reduction Ratio
1:120
T-Slot Width
14H7mm
Maximun Speed
33.3r.p.m
Positioning Button
18H7mm
Allowable Work Inertia
44.8kg.cm.sec2
Min lncrement
0.001°
Allowable Cutting Torque
80Kg.m
Weight（Without Motor）
180Kg
Vertical
150KG
Tailstock applied
350KG
WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC Machinery
WT-320-2P Machine CNC Machining Center Parts CNC Turntable Rotary Table for CNC Machinery
