YGK Series Aluminum Wire Double Card Automatic Wire Clipper

YGK Series Aluminum Wire Double Card Automatic Wire ClipperProducts DescriptionAluminium wire clipperOne set of quick-wear parts with the machine.One year of warranty for the whole machineWe visit customers periodically and can produce unique product according to customer’s requirement.We are respon......

YGK Series Aluminum Wire Double Card Automatic Wire Clipper

Products Description
YGK Series Aluminum Wire Double Card Automatic Wire Clipper
Aluminium wire clipper
One set of quick-wear parts with the machine. One year of warranty for the whole machine We visit customers periodically and can produce unique product according to customer’s requirement. We are responsible for customers and have specific after- sales team, and we are ready to solve anproblems occured during customers production timely and guickly, and provide whole life product service
Type
YGK100
Speed ​​(r/min)
120min/min
Dimensions (mm)
1520x900x1500
Machine weight (kg)
400
Power (kw)
3
Casing fold diameter (mm)
20-100
Gas source MPa
0.5-0.6
Applicable card type
2.1-2.9
The punching speed is adjustable from 1 to 9 levels, and the maximum speed for a single machine can reach 120 time/min. It uses aluminum wire to seal, and the buckle shape after punching is beautiful, and the buckle is heart-shaped. The casing folding diameter range is 20~100mm. K1, K2, and K3 molds can be replaced freely. It has automatic cutting function, and 0~9 pieces can be selected at will. The stretching distance is 36~100mm and can be adjusted in steps to meet the requirements of different fullness of products. It can be connected with a quantitative filling machine to realize automatic production. The punching center height is 950-1000mm and can be adjusted. It is equipped with multiple protections to ensure safe operation.
