The Custom Injection Molded Plastic Gear is a made-to-drawing plastic gear produced either by injection moulding (for high-volume production) or by CNC machining from MC nylon bar (for prototypes, low-volume runs and large-diameter gears). Both processes are run in-house at Raydafon, so a single supplier covers the full lifecycle from a first prototype in MC nylon through to a steel mould and high-volume injection production. The gear geometry can be spur, helical, worm, ring or internal — the process and material are selected against the load, the speed and the production volume.
Plastic gears are specified instead of metal gears where the drive benefits from lower weight, quiet running, corrosion resistance, self-lubrication or electrical insulation. The Custom Injection Molded Plastic Gear is used on automotive sub-assemblies, home appliances, office equipment, power tools, conveyor systems, speed reducers, gear pumps, motors and machine tools. Send a drawing, a 3D model or a physical sample and Raydafon will confirm the material, the process and the unit price at the required quantity.
The Custom Injection Molded Plastic Gear is a made-to-drawing plastic gear produced by injection moulding or CNC machining from MC nylon. Both processes are run in-house at Raydafon. Gear types include spur, helical, worm, ring and internal. Materials include MC nylon, POM (acetal), PA66, PEEK, UHMW-PE and other engineering plastics. Applications cover automotive sub-assemblies, home appliances, office equipment, power tools, conveyor systems, speed reducers, gear pumps, motors and machine tools. Send a drawing, 3D model or sample and Raydafon will confirm material, process and unit price against the required volume. ISO 9001 factory supply from Ningbo, China.
A Custom Injection Molded Plastic Gear is a plastic gear produced to a customer's own drawing rather than selected from a catalogue. Injection moulding is used when the annual volume justifies the cost of a steel mould: the mould is cut to the gear profile and the gears are then moulded at high cycle rates in the chosen polymer. CNC machining from MC nylon bar is used for prototypes, low-volume production, large-diameter gears and applications where the mould cost cannot be amortised. Raydafon runs both processes in-house, so the same gear can be prototyped in MC nylon and then moved to injection moulding once the design is fixed and the volume is confirmed.
Plastic gears are chosen over metal gears for five reasons: lower weight, quiet running, corrosion resistance, self-lubricating operation and electrical insulation. In low-to-medium torque applications the plastic gear often outlasts a steel gear running without lubrication, and it does so at a lower cost per unit once tooling is amortised. Where the load or speed exceeds what plastic can carry, Raydafon can quote the same gear in metal — see the related categories for spur gears, helical gears and worm gears in steel.
The Custom Injection Molded Plastic Gear is produced by one of two methods depending on the volume and the gear size. The table below summarises the two processes so the correct one can be selected before a quotation is issued.
| Parameter | Injection Moulding | CNC Machining (MC Nylon) |
|---|---|---|
| Best for | High-volume production, complex tooth profiles, integrated features | Prototypes, low-volume runs, large-diameter gears, urgent replacement |
| Tooling cost | Steel mould required (amortised over volume) | None — cut directly from MC nylon bar |
| Typical volume | 5,000 to millions of pieces per year | 1 to 5,000 pieces per year |
| Lead time | 4-8 weeks including mould cutting and first articles | 3-15 days from confirmed drawing |
| Material options | POM, PA66, PEEK, UHMW-PE, glass-filled grades | MC nylon (cast), POM, PEEK |
| Tolerance | Mould-controlled, repeatable at high volume | Machining tolerance (typically ±0.05 mm) |
| Design changes | Requires mould modification after first articles | Design changes handled immediately per piece |
The Custom Injection Molded Plastic Gear is specified over a metal gear when one or more of the six advantages below justify the choice. In most applications the reason is a combination of weight, noise and self-lubrication rather than a single factor.
A plastic gear weighs roughly one seventh of the same steel gear. On handheld tools, appliances and automotive sub-assemblies the weight saving is passed on to the end product.
Plastic damps the tooth impact that generates noise on a metal gear pair. Plastic-to-plastic and plastic-to-steel pairs run significantly quieter than an equivalent steel pair.
MC nylon and POM have a low coefficient of friction and do not require external lubrication. This eliminates the oiling step in the assembly line and removes the risk of a dry running failure.
Plastic gears do not rust in humid, washdown or chemical-vapour environments. This makes them the standard choice for food equipment, medical devices and marine applications.
Plastic gears are electrically insulating, which is used in switches, appliance mechanisms and equipment where an electrically live gear train cannot be used.
Injection moulding allows integrated features — gear, hub, shaft, boss, snap-fit and cam — to be moulded as one part. This reduces assembly steps compared with a metal gear plus separate hub.
The Custom Injection Molded Plastic Gear is specified across a wide range of industries. The application categories below are the ones most often quoted on a Raydafon enquiry.
To confirm the correct Custom Injection Molded Plastic Gear and issue a quotation, Raydafon needs the five items below. For an existing part, the original drawing and the annual volume are usually enough.
Send the five items below and Raydafon will confirm the gear type, material, process route and unit price within one working day.
A Custom Injection Molded Plastic Gear is a made-to-drawing plastic gear produced by injection moulding or by CNC machining from MC nylon. Both processes are run in-house at Raydafon. Injection moulding is used for high-volume runs with a steel mould; CNC machining from MC nylon bar is used for prototypes, low-volume production and large-diameter gears.
It depends on the volume. Injection moulding is cheaper per piece once the annual volume amortises the steel mould, and it allows complex integrated features. CNC machining has no tooling cost and is therefore better for prototypes, low-volume runs, large-diameter gears and urgent replacement orders. Raydafon can supply the same gear in either process.
Standard materials include MC nylon (cast nylon), POM (acetal), PA66 (nylon 66), PEEK and UHMW-PE. Glass-filled and carbon-filled grades are available for higher load applications. The material is selected against the torque, the operating temperature, the chemical environment and the required service life. Send the actual operating conditions and Raydafon will recommend the correct grade.
Yes. Send a physical sample and Raydafon will reverse-engineer the geometry and confirm the material, the module and the tooth profile. Where the original sample is worn, send two samples so that the unworn portions can be cross-checked. A reverse-engineered drawing is provided with the quotation.
Spur gears are the most common, but Raydafon also produces custom helical gears, worm gears, worm wheels, ring gears, internal gears and racks in plastic. Almost all gear types that were historically produced in metal can now be produced in plastic for the correct load and duty.
CNC-machined MC nylon gears hold a typical tolerance of ±0.05 mm. Injection moulded gears hold the tolerance set by the mould, which is confirmed against the drawing during first-article inspection. Lead time is 3 to 15 days for CNC-machined gears from a confirmed drawing and 4 to 8 weeks for injection moulded gears including mould cutting and first articles.
For CNC-machined MC nylon gears the MOQ is one piece. For injection moulded gears the MOQ depends on the mould cost and the annual volume; typically the tooling is justified above 5,000 pieces per year. MOQ is confirmed with the quotation once the gear geometry and the annual volume are known.
Yes. Where the load or speed exceeds what plastic can carry, Raydafon produces the same gear in steel, stainless steel, brass or aluminium. The gear geometry is unchanged, so a metal version can be specified for a high-load position in the same assembly that uses plastic gears elsewhere.
Whether you are prototyping a new gear train, moving an existing gear from metal to plastic, or sourcing a custom plastic gear in volume for a series production program, Raydafon can quote the Custom Injection Molded Plastic Gear, an MC nylon CNC-machined version, or a metal equivalent to the same drawing. OEM and project quantities supplied directly from the Ningbo factory.
