Model No | NMRV025, NMRV030, NMRV040, NMRV050, NMRV063, NMRV075, NMRV090, NMRV110, NMRV130, NMRV150 |
Ratio | 5,7.5,10,15,20,25,30,40,50,60,80,100 |
Material | Housing: Size 25-110 Is Aluminum Alloy, Size 110-150 Is Cast-Iron |
Worm Wheel: ZCuSn10Pb1 | |
Worm:20Cr | |
Pinion:Tin Bronze | |
Output Shaft: Steel-45# | |
Type | Worm Gear Speed Reducer / Gearbox / Reductor |
Color | Customized Color |
Packing | Carton, Honey Comb Carton, Wooden Case with Wooden Pallet |
Usage | Industrial Machine, Food Stuff, Ceramics, Chemical, Packing, Dyeing, Wood Working, Glass, etc. |
Flange | IEC standard flange or customized dimensions |
Housing Material | Aluminum&Cast iron |
Size | 11 sizes(WMRV25~WMRV185) |
Power | 0.06~22 KW |
Nominal torque | ≤2548 N.m |
Ratio | 5~100 |
